Strange image on FPV setup with GH4 and AV converter

P

ptaylor999

Member
Hello folks,

I'm having a heck of a time setting up my new FPV system.

Here's the gear I have:
• GH4 (I think I have all the settings correct for HDMI output)
• AerialPixels HDMI to Mini HDMI converter ( https://aerialpixels.com/shop/hdmi-a...upports-1080p/ )
• TS832 5.8G 600mw 32CH VTX ( http://www.foxtechfpv.com/ts832-58g-...tx-p-1132.html )
• Feelworld 7" Built in Battery Dual 32CH Diversity Receiver Monitor ( http://www.floridauav.com/feelworld-...r-without-dvr/ )

I've hooked everything up and am getting a picture. Problem is that the picture looks horrible! The colors are all way off.

The 2 pics below are of what I'm seeing. The first is from the screen on the back of the GH4, the way it's supposed to look. And the second is from the Feel World monitor. You can see they are both the same image, but the second (the one from the FPV monitor) is whack.




I'm not sure if the problem lies with the VTX, the Converter, or maybe my cam settings are off?

Anyone out there see something like this before?

Any advise would be Greatly appreciated.

Thanks all,

-- Pat


P

ptaylor999

Member
ptaylor999 said:
Hello folks,

I'm having a heck of a time setting up my new FPV system.

Here's the gear I have:
• GH4 (I think I have all the settings correct for HDMI output)
• AerialPixels HDMI to Mini HDMI converter ( https://aerialpixels.com/shop/hdmi-a...upports-1080p/ )
• TS832 5.8G 600mw 32CH VTX ( http://www.foxtechfpv.com/ts832-58g-...tx-p-1132.html )
• Feelworld 7" Built in Battery Dual 32CH Diversity Receiver Monitor ( http://www.floridauav.com/feelworld-...r-without-dvr/ )

I've hooked everything up and am getting a picture. Problem is that the picture looks horrible! The colors are all way off.

The 2 pics below are of what I'm seeing. The first is from the screen on the back of the GH4, the way it's supposed to look. And the second is from the Feel World monitor. You can see they are both the same image, but the second (the one from the FPV monitor) is whack.




I'm not sure if the problem lies with the VTX, the Converter, or maybe my cam settings are off?

Anyone out there see something like this before?

Any advise would be Greatly appreciated.

Thanks all,

-- Pat
Click to expand...
Waitaminute. Is that a False Color image?
